Vesta + vBox
Your Complete 4-in-1 Residential Green Energy Solution
The Vesta + vBox system integrates solar power generation, energy storage, energy management, and power supply to EV charging, suitable for both indoor and outdoor use. It reduces carbon footprint, provides backup power, and ensures efficient energy use. With the MicroGrid Interconnection Device (MID), it ensures uninterrupted power during grid outages.
- Residential
Versatile Power Management
- Combines solar power, storage, utility, and EV charging in one system to meet all your energy needs.
Direct EV Charging
- Efficiently directs power from solar panels, storage batteries, and the grid to keep your EV charged and ready to go.
Whole Home Backup
- The MID ensures automatic power switching during outages, providing continuous energy to your home.
Enhanced Safety and Durability
- Features advanced safety systems, including a Fire Control System (FCS) and Lithium Iron Phosphate (LFP) cells, for safe and reliable operation.
Modular and Scalable Design
- The vBox battery system is expandable from 7 kWh to 40 kWh, adapting as your energy demands change.
Vesta Single Phase
4-in-1 Hybrid Inverter
- Peak Efficiency: 97.40%
- Max. Input Voltage: 600V DC
- MPPT Operating Voltage Range: 80V to 500V DC
- Max. Output Power: 2800VA to 6600VA
- Grid Voltage: 220V AC / 230V AC
- Audible Noise: < 45 dB (A) @ 1m
- Interface: RS485, Bluetooth, WiFi
- Dimensions (W x H x D): 484 x 400 x 177mm
- Weight: 17kg
- Ingress Protection: IP65
Vesta Three Phase
4-in-1 Hybrid Inverter
- Peak Efficiency: 98.10%-98.40%
- Max. Input Voltage: 1000V DC
- MPPT Operating Voltage Range: 140V to 950V DC
- Max. Output Power: 6600VA to 13800VA
- Grid Voltage: 220V AC / 230V AC
- Audible Noise: < 45 dB (A) @ 1m
- Interface: RS485, Bluetooth, WiFi
- Dimensions (W x H x D): 484 x 400 x 177mm
- Weight: 17kg
- Ingress Protection: IP65
vBox
Whole Home Energy Backup
- Rated Energy: 6.9kWh – 20.7kWh
- DOD: ＞90%
- Max. Output Power: 3.2kW – 9.6kW
- Charge-discharge Rate: 0.42 C
- Dimensions (W x D x H): 799 × 218 x 767/959/1150/1342/1533mm
- Weight: 80kg – 196kg
- Ingress Protection: IP55
- Audible Noise: <30dB
MID
Microgrid Interconnect Device
- Rated Voltage: 220V/230V, 380V/400V
- Rated Frequency: 50Hz/60Hz
- Max. Output Current: 63A
- Rated Voltage: 220V/230V, 380V/400V
- Rated Frequency: 50Hz/60Hz
- Max. Output Current: 63A
- Switchover Time: ＜20ms
- Interface: RS485
- Dimensions (W x H x D): 500 x 440 x 120mm
- Ingress protection: IP65
Solution
-
Residential
Learn More
Success Story
Residential Energy Storage System Installed in Changzhou, China
Successful installation of a residential energy storage system in Changzhou, China, utilizing Vesta + vBox. The system empowers homeowners to enhance energy independence, reduce electricity costs, and contribute to sustainability efforts.
Take Control of Your Charger With
the StarCharge Home App
Remote Control and Accessibility
Control and monitor your charging sessions, adjust settings,
and receive real-time updates remotely.
Flexible Charging Schedules
Tailor your charging routines to meet lifestyle and energy
preferences.
Convenient Family Sharing
Easily share and control your chargers with multiple users.
